Excavators for Tractors

B.I.M MOSXOS (TS Series) excavators are designed and manufactured with the aim of serving any type of excavation project easily, quickly and safely.

*The ideal type of machine for you also depends on the horsepower of the tractor it is going to be mounted on. Not all excavators can be fitted to all vehicles.

excavators for tractors ts500 bim mosxos 01

excavators for tractors ts500 bim mosxos 02

excavators for tractors ts500 bim mosxos 03

excavators for tractors ts500 bim mosxos 04

TS-500

Working Radius

5,00 m

Excavation Depth

3,00 m

Excavation Force

1600 kg

Loader Width

45 cm

Loader Capacity

120 lt

Net weight

1200 kg

Lateral Displacement

Yes

Rotation

160°

Working Pressure

220 bar

excavators for tractors ts400 bim mosxos 01

excavators for tractors ts400 bim mosxos 02

TS-400

Working Radius

4,00 m

Excavation Depth

2,50 m

Excavation Force

1450 kg

Loader Width

35 cm

Loader Capacity

48 lt

Net weight

590 kg

Lateral Displacement

Yes

Rotation

160°

Working Pressure

200 bar

excavators for tractors ts300 bim mosxos 01

TS-300

Working Radius

3,00 m

Excavation Depth

1,90 m

Excavation Force

1100 kg

Loader Width

30 cm

Loader Capacity

32 lt

Net weight

480 kg

Lateral Displacement

Yes

Rotation

160°

Working Pressure

180 bar

excavators for tractors ts250 bim mosxos 02

TS-250

Working Radius

2,50 m

Excavation Depth

1,25 m

Excavation Force

950 kg

Loader Width

25 cm

Loader Capacity

17 lt

Net weight

250 kg

Lateral Displacement

Rotation

160°

Working Pressure

170 bar

excavators for tractors ts200 bim mosxos 01

TS-200

Working Radius

2,00 m

Excavation Depth

1,15 m

Excavation Force

740 kg

Loader Width

20 cm

Loader Capacity

12 lt

Net weight

190 kg

Lateral Displacement

Rotation

160°

Working Pressure

170 bar
